Calculating Frictional Pressure Loss in a Pipeline

A step-by-step procedure to calculate frictional pressure losses in a pipeline for single-phase incompressible flow using a hand calculation, and coding it in Excel VBA.


In engineering, fluid flow and programming is a big deal. A thorough understanding of fluid flow fundamentals is a requirement for any mechanical engineer. Whether you are sizing a pump for a pipeline, designing a heat exchanger, or trying to alleviate bottlenecks in pipeline gathering systems, fluid flow shows up in many cases in our profession. I want to demonstrate a step-by-step procedure to calculate frictional pressure losses in a pipeline for single-phase incompressible flow using a hand calculation. Then I will demonstrate how to code this in excel VBA so the process is repeatable for different cases.

The sample code is presented below:

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

'Gives the pressure gradient in psi/ft in a pipeline

'Uses Oil and Gas Units

Function PressureLossgradbbl(Q, D, SG, u, e)



    'Q: flow rate, bbl/day

    'D: pipeline diameter, in

    'SG: specific gravity

    'u: viscosity, sp

    'e: roughness, in



    g = 32.2

    A = WorksheetFunction.Pi() / 4 * D ^ 2



    Re = Reynoldsbbl(SG, Q, D, u)

    f = FrictionFactor(Re, e, D)



    'Darcy Weasback Equation in psi/ft

    PressureLossgradbbl = 0.433 * SG * (0.00105) * f * (1 / D) * ((Q / A) ^ 2) / (2 * g)



End Function

''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''

'Reynolds number for pipeline flow

Function Reynoldsbbl(SG, Q, D, u)



    'SG: Specific Gravity

    'Q: Flow rate,(bbl/day)

    'D: Diameter, in

    'u: viscosity, cp



    Reynoldsbbl = 92.35 * (SG * Q) / (D * u)

End Function

''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''

'Friction Factor

Function FrictionFactor(Re, e, D)

    'Re: Reynolds Number

    'e: roughness, in



    'laminar flow or turbulent('Swamee Jain Friction Factor)?

    If Re < 2100 Then

        FrictionFactor = 64 / Re

    Else

        A = e / (3.7 * D)

        b = 5.74 / (Re ^ 0.9)



    FrictionFactor = 0.25 / (WorksheetFunction.Log10(A + b) ^ 2)



    End If



End Function
